CFMOTO UFORCE 500/800 snow plow kit for UTV side by sides by KFI.

2013-2022 - UFORCE 800 EPS
2016-2020 - UFORCE 500 EPS (DOES NOT fit UFORCE 600)

CFMOTO UFORCE 500/800 UTV Snow Plow Mount, KFI (105600):

• 100% MADE IN USA
• Front-mount System (fits KFI plows only, not other brands)
• Plate constructed from 3/16” grade 50 steel
• All pin tabs are constructed from 1/4” thick grade 50 steel
• All plow tabs are tapered to help reduce hang-ups while trail riding
• Powder coated black for supreme durability
• Complete installation instructions included
• All mounting hardware included (NOTE: Requires drilling)
• Pin tabs for plow mounting are 12" width center-to-center

KFI Straight Blade (72"):

• 100% MADE IN USA
• 72" blades include a 7" high 2-ply top rubber flap
• Pushes snow straight ahead or to the sides up to 25 degrees
• Measures 16” Tall
• Fully-adjustable blade skids with bolt-on brackets
• Heavy duty 3”-diameter grade-50 steel skid plates
• Blade constructed of 11 ga steel
• 3/16” grade 50 ribbing for a strong bolt-up to the swivel tube
• Powder coated for supreme durability
• 2-Sided 3/16” x 3.00” grade 50 steel wear bar
• Wear bar attached with heavy duty grade 8 bolts
• All blades fit all KFI mount kits
• Complete installation instructions included
• All mounting hardware included

KFI Snow Plow Push Tube UTV (106300):

• Improved Manufacturing
• Easier Install For All Plow Accessories
• Added 2.5" Of Overall Length
• Works With All KFI Plows
• Front Mount Design with 30"+ of lift height
• 100% MADE IN USA
• Heavy Duty 1-1/2" 12 Gage Square Steel Tubing
• Heavy Duty 1/4" Thick 1-1/2" Diameter Grade 50 Pivot Bushings
• 6" Diameter POM Injection Molded Rotator Bushing
• Easy-Pull Pin Blade angle adjustment
• Multi-position Plow Lift Bracket
• 6 five degree blade pitch adjustments
• 3 blade angle positions that rotate the blade up to 25 Degrees
• Unlike all other Plow competitors our tubes are metal bead blasted before they are powder coated for the best possible finish prep.
• Powder Coated Black for supreme durability
• Complete installation instructions included
• All mounting hardware included

NOTE: Failing to follow the below safety rules will greatly increase the chances of damaging your plow system, machine and/or winch (if applicable). KFI will not be liable for any bending of materials as it is not caused by imperfections or defects in the material but by failing to follow these safety rules:

• Do not exceed 5 MPH, even with the blade raised.
• Make sure that all nuts and bolts are tightened per installation instructions.
• Never operate this KFI product with missing or damaged parts.
• Drive slowly over bumpy and rough terrain, driving fast could cause damage to winch (if applicable) or plow.
• Never raise the plow above point of contact as it could cause damage to machine or winch (if applicable).
• Always perform regular inspections and maintenance on plow system and hardware before use.
• Operate with extreme caution on slopes, steep grades, and rough terrain.
• Be aware of any possible hidden objects under the snow.
• Do not ram the blade into the snow pile.
